CUBS CBV Type Refrigeration Compressor Parts Brass Ball Valve CBV12S

Name: CUBS CBV Type Refrigeration Compressor Parts Brass Ball Valve CBV12S
Brand: CUBS
Price: 1 USD

Quality CUBS CBV Type Refrigeration Compressor Parts Brass Ball Valve CBV12S wholesale

Brand Name : CUBS

Model Number : CBV Series

Certification : CE

Place of Origin : China

MOQ : 1pcs

Price : discussed

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5,000pcs per month

Delivery Time : 7-10 working days after received your payment

Packaging Details : Carton box

Channel : Straight Through Type

Type : Fixed Ball Valve

Application : Industrial Usage, Water Industrial Usage, Household Usage

Material : Brass

Connection Form : Welding

Contact Now

CUBS CBV Type Refrigeration Compressor Parts Brass Ball Valve

Description

CUBS ball valves are manually operated shut-off valves suitable for bi-directional flow. GBC valves are used in liquid, suction and hot gas lines in refrigeration, freezing and air conditioning systems. GBC valves offer maximum tightness, both externally as well as internally across the seat.

CUBS valves give maximum flow in the fully open position. They are designed for operation in all temperature conditions without problems occurring as a result of liquid being trapped internally.

Features
Flow without pressure drop
¼ Turn from fully open to fully closed valve
Rotation stop for fully open and fully closed valve
Arrow on spindle top to indicate valve closed or open
Can be panel mounted
Bi-directional flow, i. E. Valve orientation is unimportant
"Hermetically" sealed welded construction
Patented spindle seal
Valve seat of special teflon
Burst-proof spindle design
The valve design prevents liquids of beeing trapped internally

RefrigerantsCFC, HCFC, HFC
Temperature of medium-40 +150° C
Ambient temperature-50 +80° C
Permissible working pressure PB35 bar
Max. Pressure46 bar
Max. Permissible leakage to atmosphere< 2.8 gram R22/year
Approvals UL, CSA

type	in	type	in
Without detection mouth		Take detection mouth
CBV6S	1/4"	CBVdD6S	1/4"
CBV10S	3/8"	CBVD10S	3/8"
CBV12S	1/2"	CBVD12S	1/2"
CBV16S	5/8"	CBVD16S	5/8"
CBV18S	3/4 "	CBVD18S	3/4 "
CBV22S	7/8"	CBVD22S	7/8"
CBV28S	1-1/8"	CBVD28S	1-1/8"
CBV35S	1-3/8"	CBVD35S	1-3/8"
CBV42S	1-5/8"	CBVD42S	1-5/8"
CBV54S	2-1/8"	CBVD54S	2-1/8"
CBV67S	2-5/8"	CBVD67S	2-5/8"
CBV79S	3-1/8"	CBVD79S	3-1/8"
CBV102S	4"	CBVD102S	4"
